A firewall is a computer network security system that restricts internet traffic in, out, or within a private network.
This software or dedicated hardware-software unit functions by selectively blocking or allowing data packets. It is typically intended to prevent anyone—inside or outside a private network—from engaging in unauthorized web activities and to help prevent malicious activity.
Firewalls can be viewed as gated borders or gateways that manage the travel of permitted and prohibited web activity in a private network. The term comes from the concept of physical walls being barriers to slow the spread of fire until emergency services can extinguish it. Comparably, network security firewalls are for web traffic management — typically intended to slow the spread of web threats.
Firewalls create 'choke points' to funnel web traffic, at which they are then reviewed on a set of programmed parameters and acted upon accordingly. Some firewalls also track the traffic and connections in audit logs to reference what has been allowed or blocked.
Firewalls are typically used to gate the borders of a private network or its host devices. As such, firewalls are one security tool in the broader category of user access control. These barriers are typically set up in two locations — on dedicated computers on the network or the user computers and other endpoints themselves (hosts).
The invention of the firewall should be viewed as an 'ongoing'. This is because it's constantly evolving, and there have been multiple 'creators' involved in its development and evolution.
From the late 1980s to the mid-90s, each creator expanded on various firewall-related components and versions before it became the product used as the basis for all modern firewalls.
In the late 1980s, Mogul, Reid, and Vixie each had roles at Digital Equipment Corp (DEC) in developing packet-filtering technology that would become valuable in future firewalls. This led to the concept of vetting external connections before they make contact with computers on an internal network. While some may consider this packet filter as the first firewall, it was more of a component technology that supported the "true" firewall systems to come.
In the late 80s to early 90s, the various staff at AT&T Bell Labs researched and developed the early concept of the circuit-level gateway firewall. This was the first firewall to vet and permit ongoing connections versus repeatedly reauthorizing after each data packet. Presotto, Sharma, and Nigam developed the circuit-level gateway from 1989 to 1990 and were followed by Cheswick and Bellovin's work with firewall technology in 1991.
From 1991 to 1992, Ranum invented the security proxies at DEC that became a vital component of the first application-layer firewall product —1991's proxy-based Secure External Access Link (SEAL) product. This was an expansion on Reid, Vixie, and Mogul's work at DEC, and was the first commercially released firewall.
From 1993 to 1994 at Check Point, the company's founder Gil Shwed and a prolific developer Nir Zuk played significant roles in developing the first widely-adopted, user-friendly firewall product—Firewall-1. Gil Shwed invented and filed the U.S. patent for stateful inspection in 1993. This was followed by Nir Zuk's work on an easy-to-use graphical interface for 1994's Firewall-1, which was vital in the wider adoption of firewalls into businesses and homes for the foreseeable future.
These developments were essential in shaping the firewall product we know today, with each being used in some capacity in many cybersecurity solutions.
Networks without protection are vulnerable to any traffic that is trying to access your systems. Harmful or not, network traffic should always be vetted.
Connecting personal computers to other IT systems or the internet opens up a range of positive possibilities. Easy collaboration with others, combining resources, and enhanced creativity can come at the cost of complete network and device protection. Hacking, identity theft, malware, and online fraud are common threats users could face when they expose themselves by linking their computers to a network or the internet.
Once discovered by a malicious actor, your network and devices can easily be found, rapidly accessed, and exposed to repeated threats. Around-the-clock internet connections elevate the risk of this (since your network can be accessed at any time).
Proactive protection is critical when using any sort of network. Users can protect from the very worst dangers by erecting an invisible wall to filter out those threats. Fortunately, an invisible wall already exists — it is known as a firewall.
A firewall decides which network traffic is allowed to pass through and which traffic is deemed dangerous. It essentially works by filtering out the good from the bad, or the trusted from the untrusted. However, before we go into detail, we must first understand the structure of web-based networks before explaining how a firewall operates to filter between them.
Firewalls are intended to secure the private networks and the endpoint devices within, known as network hosts.
Network hosts are devices that "talk" with other hosts on the network. They send and receive between internal networks, as well as outbound and inbound between external networks.
Your computers and other endpoint devices use networks to access the internet — and each other. However, the internet is segmented into sub-networks or 'subnets' for security and privacy.
The basic subnet segments are as follows:
Screening routers are specialized gateway computers placed on a network to segment it. They are known as house firewalls on the network-level. The two most common segment models are the screened host firewall and the screened subnet firewall.
As mentioned earlier, both the network perimeter and host machines themselves can house a firewall. To do this, it is placed between a single computer and its connection to a private network.
Network firewalls require configuration against a broad scope of connections, whereas host firewalls can be tailored to fit each machine's needs. However, host firewalls require more effort to customize, meaning that network-based are ideal for a sweeping control solution. But the use of both firewalls in both locations simultaneously is ideal for a multi-layer security system.
Filtering traffic via a firewall makes use of pre-set or dynamically learned rules for allowing and denying attempted connections. These rules are how a firewall regulates the web traffic flow through your private network and private computer devices. Regardless of type, all firewalls may filter by some blend of the following:
Source and destination are communicated by internet protocol (IP) addresses and ports. IP addresses are unique device names for each host. Ports are a sub-level of any given source and destination host device, similar to office rooms within a larger building. Ports are typically assigned specific purposes, so certain protocols and IP addresses utilizing uncommon ports or disabled ports can be a concern.
By using these identifiers, a firewall can decide if a data packet attempting a connection is to be discarded—silently or with an error reply to the sender—or forwarded.
The concept of a network security firewall is meant to narrow the attack surface of a network to a single point of contact. Instead of every host on a network being directly exposed to the greater internet, all traffic must first contact the firewall. Since this also works in reverse, the firewall can filter and block non-permitted traffic, in or out. Also, firewalls are used to create an audit trail of attempted network connections for better security awareness.
Since traffic filtering can be a rule set established by owners of a private network, this creates custom use cases for firewalls. Popular use cases involve managing the following:
Notably, firewalls are not very effective at the following:
The different types of firewalls incorporate varied methods of filtering. While each type was developed to surpass previous generations of firewalls, much of the core technology has passed between generations.
Firewall types are distinguished by their approach to:
Each type operates at a different level of the standardized communications model, the Open Systems Interconnection model (OSI). This model gives a better visual of how each firewall interacts with connections.
Static packet-filtering firewalls, also known as stateless inspection firewalls, operate at the OSI network layer (layer 3). These offer basic filtering by checking all individual data packets sent across a network, based on where they're from and where they're attempting to go. Notably, previously accepted connections are not tracked. This means each connection must be re-approved with every data packet sent.
Filtering is based on IP addresses, ports, and packet protocols. These firewalls, at the bare minimum, prevent two networks from directly connecting without permission.
Rules for filtering are set based on a manually created access control list. These are very rigid and difficult to cover unwanted traffic appropriately without compromising network usability. Static filtering requires ongoing manual revision to be used effectively. This can be manageable on small networks, but difficult on larger ones.
Audit logs are not available with packet filter firewalls. This can make tracking past and ongoing attacks challenging, which is less than ideal for sizable networks.
Lack of ability to read application protocols means the contents of a message delivered within a packet cannot be read. Without reading the content, packet-filtering firewalls have a limited quality of protection.
Circuit-level gateways operate on the transport layer (layer 4). These firewalls check for functional packets in an attempted connection, and—if operating well—will permit a persistent open connection between the two networks. The firewall stops supervising the connection after this occurs.
Aside from its approach to connections, the circuit-level gateway can be similar to proxy firewalls.
The ongoing unmonitored connection is dangerous, as legitimate means could open the connection and later permit a malicious actor to enter uninterrupted.
Stateful inspection firewalls, also called dynamic packet-filtering firewalls, are unique from static filtering in their ability to monitor ongoing connections and remember past ones. Similar to circuit-level firewalls, these began by operating on the transport layer (layer 4). Nowadays, these firewalls can monitor many layers, including the application layer (layer 7).
Like the static filtering firewall, stateful inspection firewalls allow or block traffic based on technical properties, such as specific packet protocols, IP addresses, or ports. However, these firewalls also uniquely track, and filter based on the state of connections using a state table.
This firewall updates filtering rules based on past connection events logged in the state table by the screening router.
Generally, filtering decisions are often based on the administrator's rules when setting up the computer and firewall. However, the state table allows these dynamic firewalls to make their own decisions based on previous interactions it has "learned" from. For example, traffic types that caused disruptions in the past would be filtered out in the future. Stateful inspection's flexibility has cemented it as one of the most ubiquitous types of shields available.
Proxy Firewalls, also known as application-level firewalls (layer 7), are unique in reading and filtering application protocols. These combine application-level inspection, or "deep packet inspection (DPI)," and stateful inspection.
A proxy firewall is as close to an actual physical barrier as it's possible to get. Unlike other types of firewalls, it acts as an additional two hosts between external networks and internal host computers, with one as a representative (or "proxy") for each network.
Filtering is based on application-level data rather than just IP addresses, ports, and basic packet protocols (UDP, ICMP) like in packet-based firewalls. Reading and understanding FTP, HTTP, DNS, and other commands allow for more in-depth investigation and cross-filtering for many different data traits.
As a guard at a doorway, it essentially looks at and evaluates incoming data. If no problem is detected, the data is allowed to pass through to the user.
The downside to this kind of heavy security is that it sometimes interferes with incoming data that isn't a threat, leading to functionality delays.
Evolving threats continue to demand more intense solutions, and next-generation firewalls stay on top of this issue by combining the features of a traditional firewall with network intrusion prevention systems.
Threat-specific next-generation firewalls are designed to examine and identify specific dangers, such as advanced malware, at a more granular level. More frequently used by businesses and sophisticated networks, they provide a holistic solution to filtering out dangers.
As implied by the name, hybrid firewalls use two or more firewall types in a single private network.
In practice, a firewall has been a topic of both praise and controversy due to its real-world applications. While there is a decorated history of firewall accomplishments, this security type must be implemented correctly to avoid exploits. Additionally, firewalls have been known to be used in ethically questionable ways.
Since 1998, China has had internal firewall frameworks in place to create its carefully monitored intranet. By nature, firewalls allow for the creation of a customized version of the global internet within a nation. They accomplish this by preventing select services and info from being used or accessed within this national intranet.
National surveillance and censorship allow for the ongoing suppression of free speech while maintaining its government's image. Furthermore, China's firewall allows its government to limit internet services to local companies. This makes control over things like search engines and email services much easier to regulate in favor of the government's goals.
Naturally, China has seen an ongoing internal protest against this censorship. The use of virtual private networks and proxies to get past the national firewall has allowed many to voice their dissatisfaction.
In 2020, a misconfigured firewall was just one of many security weaknesses that led to an anonymous United States federal agency's breach.
It is believed that a nation-state actor exploited a series of vulnerabilities in the U.S. agency's cybersecurity. Among the many cited issues with their security, the firewall in-use had many outbound ports that were inappropriately open to traffic. Alongside being maintained poorly, the agency's network likely had new challenges with remote work. Once in the network, the attacker behaved in ways that show clear intent to move through any other open pathways to other agencies. This type of effort puts not only the infiltrated agency at risk of a security breach but many others as well.
In 2019, a United States power grid operations provider was impacted by a Denial-of-Service (DoS) vulnerability that hackers exploited. Firewalls on the perimeter network were stuck in a reboot exploit loop for roughly ten hours.
It was later deemed to be the result of a known-but-unpatched firmware vulnerability in the firewalls. A standard operating procedure for checking updates before implementation hadn't been put into place yet causing delays in updates and an inevitable security issue. Fortunately, the security issue did not lead to any significant network penetration.
These events are another strong indicator of the importance of regular software updates. Without them, firewalls are yet another network security system that can be exploited.
Proper setup and maintenance of your firewall are essential to keep your network and devices protected.
Here are some tips to guide your firewall security practices:
